Decanter Centrifuge
what is Decanter Centrifuge?
Decanter centrifuge is used to separate drilling cuttings out of drilling mud as the 5th phase cleaning in the whole sol...
what is Decanter Centrifuge?
Decanter centrifuge is used to separate drilling cuttings out of drilling mud as the 5th phase cleaning in the whole sol...
Decanter centrifuge is an important component of solids control. AIPU centrifuges achieve effective fine solids separation, or barite recovery in drilling fluids system in onshore/offshore O&G drilling, drilling waste management, as well as the dewatering process. We supply various options of decanter centrifuge to meet certain client’s demand, including middle speed centrifuge, high speed decanters, VFD high speed centrifuge, hydraulic drive centrifuges. Centrifuges are operated after desilter or mud cleaner to separate particles between 2 to 7 microns. And for centrifuge feeding pump, there are 2 options mainly, the screw pump and submersible slurry pump. Depending on users’ preference and actual condition, we’ll propose an optimal one.
| Model | APLW450×842N | APLW450×1000N | APGLW355×1258D-N | APGLW450×1258D-N | APGLW530×1320D-N |
|---|---|---|---|---|---|
| Drum Dia. | φ450mm | φ450mm | φ355mm | φ450mm | φ530mm |
| Drum Length | 842mm | 1000mm | 1258mm | 1258mm | 1320mm |
| Lambda Ratio | 1.9 | 2.2 | 3.5 | 2.8 | 2.5 |
| Drum Shape | Conical | ||||
| Speed | 1800rpm | 2200rpm | 3200rpm | 3000rpm | 2800rpm |
| Main Motor | 22Kw | 30Kw | 30Kw | 37Kw | 55Kw |
| Accessory Motor | 5.5Kw | 7.5Kw | 7.5Kw | 11Kw | 11Kw |
| Max. Capacity | 40m³/h | 50m³/h | 35m³/h | 60m³/h | 65m³/h |
| Separation Point | 5~7microns | 2-5microns | |||
| Separation Factor | 815G | 1215G | 2035G | 2250G | 1817G |
| Suggesting Pump | 4kw (submersible) | 5.5kw(submersible) | 7.5kw(submersible) | ||
| Reference Dimension | 2600×1550×1650mm | 2750×1550×1700mm | 2900×1480×1650mm | 2900×1550×1650mm | 3300×1700×1750mm |
| Weight | 3000kg | 3200kg | 3000kg | 3200kg | 4000kg |
Customizable Options for APLW Mud Decanter Centrifuge
Facing the international market, based on the actual needs of users, AIPU provides flexible configuration for customers. The following are the main optional parameters:
Electrical System - Customizable
Material - Material optional (Typically refers to stainless steel grade or other material specifications)
Certifications - ATEX, IEC, DGMS, UL etc. certificates are optional
Surface Color
Additional Optional Component
Control Cabinet - Pressurized EX Proof VFD (Variable Frequency Drive) control cabinet available.
As the top solid control manufacturer in China, Aipu Solid Control always puts customer needs first. We firmly believe that technology can create the future, but service is the bridge that turns technical strength into real value for customers.Aipu Control insists on providing high-quality products and services. And it is an honor to be your ideal global supplier of drilling fluid treatment equipment. Looking forward to serving you.
