Shear Pump
what is Shear Pump?
Shearing pump is designed to reduce cost of mixing polymers and clays while improving mud properties, it shear the polym...
what is Shear Pump?
Shearing pump is designed to reduce cost of mixing polymers and clays while improving mud properties, it shear the polym...
Shearing pump is designed to reduce cost of mixing polymers and clays while improving mud properties, it shear the polymers eliminates fish eyes and prevents polymer chaining which can’t pass though the shaker screen.
Drilling mud shear pumps are an essential component of the circulating system in drilling operations. Their primary function is to provide the necessary pressure and flow rate to circulate the drilling fluid (mud) through the drill string, out the bit nozzles, and back up the annulus.
Shearing Action
1. As the drilling mud is pumped through the bit nozzles at high velocity, it experiences intense shear forces that help emulsify and condition the mud.
2. This shearing action improves the rheological properties of the mud, such as viscosity and gel strength, which aids in cutting removal and suspension.
Adopting comprehensive mechanical seal technology, innovative and unique design, pioneering advanced sealing performance both domestically and internationally, reliable operation, and long service life
Using the APJQB series shear pump can save more than 30% of bentonite
Provide high shear force for rapid hydration of polymer (or clay) and solve the prominent problem of poor hydration of polymer (or clay) in drilling fluid
The mud cake and fluid loss are reduced, the shear ratio rate of drilling fluid is reduced, and the strength of gel is improved, thus reaching the advanced level of foreign products
| Model | Capacity | Head | Motor | Weight | Size(mm) |
|---|---|---|---|---|---|
| APJQB6545 | 120m³/h | 45m | 55kw | 980kg | 1150×1100×1500 |
| APJBQ6535 | 100m³/h | 35m | 45kw | 800kg | 1150×1100×1250 |
FAG, SKF or other top brand bearing
SOG oil seal
Standard options : IECEX, ATEX, UL, DGMS, CE, Gost
