Screw Conveyor
what is Screw Conveyor?
Screw conveyor is also referred to Auger feeder. They can be used as the transfer unit of drilling cuttings to cuttings ...
what is Screw Conveyor?
Screw conveyor is also referred to Auger feeder. They can be used as the transfer unit of drilling cuttings to cuttings ...
Screw conveyor is also called auger feeder. Usually, the screw diameter has 4 options: 10 inch, 12inch, 16 inch, 20 inch; screw length is customer built too, but commonly there are 12~48feet. Furthermore, depends on clients’ demand the screw conveyor will be made of different materials. Including carbon steel, stainless steel graded differently.
Screw conveyor is also referred to Auger feeder. They can be used as the transfer unit of drilling cuttings to cuttings dryer, also the unit to transfer disposal to cuttings tank or collection container. The length can be custom built according to actual working condition.
Actually the auger feeder is not only used in oilfield waste management but also other applications. Such as chemical industry, construction industry, food industry, mining industry, and so on. The angle of conveyor is customizable for different work site. For cuttings transfer, we usually use U type conveyor and round tube type conveyor.
● Compact design
● Good sealing effect
● Easy to use and maintain
● Stable and reliable performance
● Customized service for customers
● Flexible customization of inlet and outlet
● The power part is a high-quality well-known brand
| Model | Power | Diameter | Length | Horizontal Capacity |
|---|---|---|---|---|
| APLS10-40 | 5.5kw | 250mm | 12m | 15m³/h |
| APLS12-30 | 5.5kw | 300mm | 9m | 20m³/h |
| APLS14-30 | 7.5kw | 350mm | 9m | 20m³/h |
| APLS14-40 | 11kw | 350mm | 12m | 30m³/h |
| APLS16-30 | 15kw | 400mm | 9m | 45m³/h |
| APLS18-30 | 15kw | 450mm | 9m | 55m³/h |
The power part is from a high-quality well-known brand;
Easy customization for users;
For more specifications and requirements, please contact us for customized services
